CNMG-TRR
Двухсторонние тригональные пластины для чистовой и получистовой обработки жаропрочных сплавов
| Название | Остаток | BRAND | L | IC | S | RE | ap (min) | ap (max) | ft (min) | ft (max) | |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CNMG 120404-TRR 913TPP | 0 | XTMT | 12.90 | 12.70 | 4.76 | 0.40 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 120404-TRR 80TSP | 0 | XTMT | 12.90 | 12.70 | 4.76 | 0.40 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 120408-TRR 913TPP | 0 | XTMT | 12.90 | 12.70 | 4.76 | 0.80 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 120408-TRR 80TSP | 0 | XTMT | 12.90 | 12.70 | 4.76 | 0.80 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 120412-TRR 913TPP | 0 | XTMT | 12.90 | 12.70 | 4.76 | 1.20 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 120412-TRR 80TSP | 0 | XTMT | 12.90 | 12.70 | 4.76 | 1.20 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 160608-TRR 913TPP | 0 | XTMT | 16.12 | 15.88 | 6.35 | 0.80 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 160608-TRR 80TSP | 0 | XTMT | 16.12 | 15.88 | 6.35 | 0.80 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 160612-TRR 80TSP | 0 | XTMT | 16.12 | 15.88 | 6.35 | 1.20 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 160612-TRR 913TPP | 0 | XTMT | 16.12 | 15.88 | 6.35 | 1.20 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 190612-TRR 913TPP | 0 | XTMT | 19.30 | 19.05 | 6.35 | 1.20 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 190612-TRR 80TSP | 0 | XTMT | 19.30 | 19.05 | 6.35 | 1.20 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 190616-TRR 80TSP | 0 | XTMT | 19.30 | 19.05 | 6.35 | 1.60 | 0.50 | 4.00 | 0.10 | 0.30 | |
| CNMG 190616-TRR 913TPP | 0 | XTMT | 19.30 | 19.05 | 6.35 | 1.60 | 0.50 | 4.00 | 0.10 | 0.30 |
Количество в упаковке : 10
